Frezite - Catálogo Geral - Catalogo General - page 291

8
8.9 www.frezite.com
A234
MAN HW D L2 S Z Ref.LH Ref.RH
S=M8
5 43 M8 2 A234.005.343.50 A234.005.243.50
6 43 M8 2 A234.006.343.50 A234.006.243.50
8 43 M8 2 A234.008.343.50 A234.008.243.50
10 43 M8 2 A234.010.343.50 A234.010.243.50
12 43 M8 2 A234.012.343.50 A234.012.243.50
S=M10
5 43 M10 2 A234.005.043.50 A234.005.143.50
6 43 M10 2 A234.006.043.50 A234.006.143.50
8 43 M10 2 A234.008.043.50 A234.008.143.50
10 43 M10 2 A234.010.043.50 A234.010.143.50
12 43 M10 2 A234.012.043.50 A234.012.143.50
D L2 S/D1 Z Ref.LH Ref.RH
S=M8
5 30 M8 / 9 2 A234.005.340.51 A234.005.240.51
6 30 M8 / 9 2 A234.006.340.51 A234.006.240.51
8 30 M8 / 9 2 A234.008.340.51 A234.008.240.51
10 30 M8 / 9 2 A234.010.340.51 A234.010.240.51
12 30 M8 / 9 2 A234.012.340.51 A234.012.240.51
S=M10
5 40 M10 /11 2 A234.005.040.51 A234.005.140.51
6 40 M10 /11 2 A234.006.040.51 A234.006.140.51
8 40 M10 /11 2 A234.008.040.51 A234.008.140.51
10 40 M10 /11 2 A234.010.040.51 A234.010.140.51
12 40 M10 /11 2 A234.012.040.51 A234.012.140.51
D L2 S Z Ref.LH Ref.RH
S=M10
5 40 M10 2 A234.005.040.52 A234.005.140.52
6 40 M10 2 A234.006.040.52 A234.006.140.52
8 40 M10 2 A234.008.040.52 A234.008.140.52
10 40 M10 2 A234.010.040.52 A234.010.140.52
12 40 M10 2 A234.012.040.52 A234.012.140.52
Brocas para furo cego com encabadouro roscado
Brocas para agujero ciego con mango roscado
